Eaton produces capacitor subsystems for shunt series hvdc svc and filtering applications throughout the world.

Eaton medium voltage capacitor bank.

Ge s high voltage capacitor bank equipment is offered in three primary types of fusing schemes. Gem series fixed capacitors. Ge also supplies active filtering equipment and line load reactors for specific line and load applications. Eaton s comprehensive line of cooper power series open air bank solutions are available in externally fused fuseless or internally fused designs.

For capacitor banks with units containing discharge. For capacitor banks with units containing discharge resistors designed to discharge the capacitor unit from peak rated voltage to less than 50 v in five 5 minutes wait at least five 5 minutes before re energizing the bank after it has been disconnected from the system. Designed manufactured and tested to meet or exceed the requirements of applicable ansi ieee iec standards these capacitors are a simple economical and reliable source of reactive power on. Eaton s mv autovar product line is comprised of metal enclosed medium voltage capacitor banks for applications with varying plant power factors.

Each design is custom configured in a variety of parallel series combinations to meet a full range of application needs based on kvar requirements system voltage protection strategy and system solutions. High voltage capacitor banks. Eaton s comprehensive cooper power series metal enclosed capacitor bank portfolio provides a compact and environmentally friendly solution. Ge provides solutions for high voltage pfc power factor control and filtering.

The eaton univar mv 2 4kv to 4 8kv 5kv class are capacitors for medium voltage heavy duty applications where a fixed amount of capacitance kvar is required. Eaton s cooper power series power capacitor products are designed for worldwide utility and industrial applications for system voltages from 2 4 kv through ehv. Eaton s cooper power series medium voltage single phase all film unfused capacitors feature extended foil elements solderless connections and laser cut aluminum foil in a high stacking factor design. Correction and harmonic mitigation in the range of 240v through 13 2kv.

This capacitor system which is housed within a nema 3r modular enclosure automatically switches stages of capacitance in and out based on information collected by the power factor controller on the door in door control panel. Enclosures are 16 gauge steel finished with durable baked on enamel and are gasketed for weatherproof dustproof applications. Pdf 626 kb 11 30 2016 pole mounted three phase capacitor bank installation operation and maintenance instructions. Internally fused externally fused and fuseless ge can analyze your network thoroughly and help you to choose the design that best fits your specific requirements.

Ge supplies low voltage and medium voltage fixed and automatically switched capacitors for power factor.
